Manufacturer: Kalstein
Dryshipper Series for Transportation (Round Canisters) is designed for safe sample transportation under cryogenic conditions (vapour phase storage, temperature under -190°C). Since the risk of LN2 release is avoided, it is suitable for air transportation of samples.
Adsorbent materials are used to absorb and retain LN2 for safe transport. No spillover of LN2 can occur even when the tank is capsized.
Special stainless steel mesh divides storage space and LN2 absorbents to prevent absorbent materials from contaminating the samples.
All models are offered a variety of stainless steel canisters
and polycarbonate cryogenic boxes. Locking cover is
optional.
Model | YR053346 | YR053347 | YR053348 | YR053349 | YR053350 | YR053351 | |
Maximum Storage Capacity | No. of Canister | 1 | |||||
No. of Straws (0.5ml / EA) |
132 | 374 | 854 | — | |||
No. of Straws (0.25ml / EA) |
298 | 837 | 1940 | — | |||
No. of 2.0 ml Cryovials | — | 100 | 300 | 500 | |||
No. of Boxes in( 2ml per holder) | — | 4 | 3 | 5 | |||
Performance | Volume of LN (L) | 3 | 6 | 10 | 15 | 25 | |
Absorbable Volume of LN2 (L) | 1.3 | 2.9 | 3.4 | 6 | 9 | ||
Static Evapouration* (L/Day) | 0.16 | 0.2 | 0.43 | 1.5 | 0.89 | ||
Liquid Phase Static Holding Time**(Day) | 20 | 37 | 23 | 10 | 29 | ||
Liquid Phase Static Holding Time**(Day) | 8 | 14 | 8 | 4 | 10 | ||
Dimensions | Opening Diameter (mm) | 50 | 80 | 125 | 216 | 216 | |
Height (mm) | 435 | 487 | 625 | 540 | 716 | ||
Outside Diameter (mm) | 223 | 300 | 300 | 394 | 394 | ||
Canister Outside Diameter (mm) | 38 | 63 | 97 | — | |||
Outside Height (mm) | 120 | 120 | 120 | — | |||
Empty Weight (kg) | 3.2 | 4.9 | 6.7 | 8.5 | 15 | ||
Full Weight (kg) | 4.7 | 7.5 | 11 | 25 | 30 | ||
Shipping Weight (kg) | 5.5 | 7.7 | 9.7 | 15.2 | 20.5 | ||
Additional Features | Includes 1 canister (height 120mm), lockable cap and protective jacket |
Includes 1 canister (height 120mm), lockable cap and protective jacket |
Includes 1 rack (4 layers), 5*5 cryoboxes, lockable cap and protective jacket |
Includes lockable cap and protective jacket, no rack |
Includes 1 rack (3 layers), 9*9 cryoboxes and lockable cap, no protective jacket |
Includes 1 rack (5 layers), 9*9 cryoboxes and lockable cap, no protective jacket |
Weight | N/A |
---|---|
Model | YR053346, YR053347, YR053348, YR053349, YR053350, YR053351 |
