Description
The Benchtop Conductivity/DO Meter YR06384 is an advanced measuring device designed to provide precise and reliable results in conductivity and dissolved oxygen measurements. It features a 7-inch colored capacitive touch screen with high resolution and sensitivity, making it easy to operate. Equipped with a built-in microprocessor chip, this meter offers intelligent functions including automatic calibration, data storage, and wireless Bluetooth capabilities for real-time data transfer. Its smart electrode status display ensures accuracy in usage, supporting various measurement modes such as conductivity, TDS, salinity, and resistivity.
Market Price
In the current market, benchtop conductivity/DO meters similar to the YR06384 are priced between approximately $1,200 and $2,000. This range reflects the high-quality components and advanced technology that these meters incorporate, ensuring reliable and precise readings, which are essential in professional and industrial settings.
Frequently Asked Questions
What is the measurement range for conductivity? The YR06384 measures conductivity in several ranges from 0.00 to 200.0 mS/cm.
Does it have temperature compensation? Yes, it automatically compensates temperature from 0 to 50 ºC.
Advantages and Disadvantages
Advantages: High precision and intelligent features like automatic calibration and Bluetooth connectivity. The device also supports automatic temperature, salinity, and pressure compensation.
Disadvantages: Advanced features might require a learning curve for new users, and the initial investment is higher than standard models due to its sophisticated capability.
Field Use
This meter is utilized in laboratories and industrial fields for monitoring and managing water quality. The Bluetooth data transfer function allows professionals to analyze real-time data efficiently, increasing productivity and accuracy in various applications.
Recommendations
To maximize the utility and lifespan of your YR06384, regular calibration and cleaning of the electrodes are recommended. Familiarize yourself with the user manual for optimal configurations and explore our platform Kalstein Plus to request a quote or more details.
Features
- 7-inch capacitive touch screen
- Intelligent functions with built-in microprocessor chip
- Bluetooth wireless data transfer option
- Stores up to 1000 test data sets
- Supports multiple measurement modes
Technical Specifications
| Model | YR06384 | |
|
Cond.
|
Measuring range
|
Conductivity: |
| (0.00~20.00)μS/cm, (20.0~200.0)μS/cm | ||
| (200~2000)μS/cm, (2.00~20.00)mS/cm | ||
| (20.0~200.0)mS/cm, | ||
| (200~2000)mS/cm (K=10) | ||
| TDS:(0 ~ 100)g/L | ||
| Salinity:(0 ~ 100)ppt | ||
| Resistivity:(0 ~ 100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1mS/cm | |
| Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS | |
| Temp. compensation range | (0 ~ 50)ºC, auto | |
| Electrode constant | 0.1/0.5/1/5/10/50/100 cm-1 | |
| Reference Temp. | 25ºC,20ºC,18ºC | |
|
DO
|
Measuring range | (0 ~ 20.00)mg/L(ppm) (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm) 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp compensation | (0 ~ 45)ºC, auto | |
| Salinity compensation | (0 ~ 45) ppt, auto | |
| Pressure compensation | (80 ~ 105) kPa, auto | |
| Auto calibration | Air saturated by water; water saturated by air | |
| Electrode type | Polarographic | |
|
Temp.
|
Range | (-10 ~ 110)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
|
Other
|
Display | 7-inch colored capacitive touch screen |
| Data storage | 1000 sets | |
| Power | 12V/1A | |
| Output | USB, RS232, Bluetooth | |
| Ambient Temp. | 15 ~ 30 ºC | |
| Ambient Humidity | ≤85% | |
| IP grade | IP54 | |
| Dimensions/N.W. | 240×170×70mm/600g | |
| Shipping Size/G.W. | 470x430x85mm/2.6kg | |
