Fluorescent LED Microscope, semi-APO, Trinocular YR06649

The YR06649 Semi-APO Trinocular LED Fluorescence Microscope is an advanced solution for laboratories requiring high-precision fluorescence observation, combining a Plan Infinity optical system, an integrated 5 W LED fluorescence unit, and a Seidentopf trinocular configuration that facilitates digital documentation and prolonged work with maximum comfort. Its design supports 1 or 2 fluorescence filters (B and G), making it a versatile tool for applications in cell biology, microbiology, histology, biomedical research, and university teaching. It is equipped with Infinity Plan objectives (4x, 10x, 40x, and 100x oil immersion) featuring an iris diaphragm, delivering sharp, flat images with excellent chromatic correction. In addition, it can be upgraded to semi-APO fluorescence objectives and a 100x water immersion objective, allowing performance to scale according to laboratory needs. The high-brightness 6 V / 30 W halogen illumination system, combined with a swing-out condenser NA 0.9/0.13, ensures optimal contrast across multiple observation techniques. In the market, this type of trinocular fluorescence microscope is positioned within a competitive price range compared to premium brands, offering an excellent cost-to-performance ratio for institutions seeking reliable fluorescence capabilities without oversizing their investment. Thanks to its modular configuration and professional optics, the YR06649 is a solid choice for both growing laboratories and established research centers.

Frequently Asked Questions

What types of applications does the YR06649 support? It is designed for fluorescence observation in biology, microbiology, pathology, academic research, and quality control. Can a digital camera be attached? Yes. Its trinocular head allows the integration of cameras for documentation, image analysis, and teaching. Is it possible to expand the optical system? Yes. The microscope can be upgraded with semi-APO fluorescence objectives and a 100x water immersion objective. Which filters are included? It includes B and G filters, with configuration options according to specific requirements.

Advantages and Disadvantages

Advantages

• High-precision Plan Infinity optical system
• Integrated LED fluorescence with low power consumption and long service life
• Ergonomic Seidentopf trinocular head
• Large, stable mechanical stage (182 × 140 mm)
• Scalable through objective upgrades

Possible Disadvantages

• Not a confocal microscope (not intended for ultra-high-resolution 3D imaging)
• Requires appropriate filter configuration depending on the specific application

Field Use of the Product

In real laboratory environments, the YR06649 microscope is used for the detection of fluorescent markers, analysis of cellular structures, identification of microorganisms, and advanced teaching practices. Its large mechanical stage with double sliding support facilitates work with multiple slides, while the 360° rotating head and adjustable interpupillary distance (48–76 mm) enhance ergonomics during prolonged sessions. It is particularly useful in university laboratories, clinical research centers, and biological control laboratories.

Recommendations

To maximize microscope performance, it is recommended to select the appropriate fluorescence filters according to the fluorophore used, perform regular cleaning of objectives and eyepieces, and carry out periodic optical calibrations. For advanced applications, adding a digital camera and image analysis software significantly expands its analytical and documentation capabilities.

Technical Specifications

Model	YR06649
Head type	Trinocular Seidentopf
Optical system	Infinity Plan
Optical characteristics	Infinity
Objectives	Infinity Plan: PLAN 4x/0.10, WD = 2.10 mm; PLAN 10x/0.25, WD = 4.64 mm; PLAN 40x/0.66, WD = 0.65 mm; PLAN 100x/1.25 (oil), WD = 0.12 mm
Objective type	Infinity Plan
Objective features	Iris diaphragm
Revolving nosepiece	5-position
Nosepiece type	Internal
Eyepieces	WF 10x / 22 mm, 2 units
Eyepiece diameter	30.0 mm
Eyepiece features	Adjustable diopter / Super WF ≥ 23 mm
Main light path	E100:P0 / E20:P80 (depending on configuration)
Interpupillary distance	48 – 76 mm
Head rotation	360° rotatable eyepiece tube
