Description
Key Features
- Srong and lightweight aluminium construction
- Heavy duty lockable enclosure offers excellent security
- Numbered index location points for canisters
- Straw storage
- LN₂ dispense pump available
- Roller bases available
- High thermal eff iciency
- 5 year vacuum warranty
- Ultra-low evapouration loss
- Numbered Index Canister Locations
- High Capacity
- High Thermal Eff iciency
- 5 Year Vacuum Warranty
- Extended Hold Time
- LN Dispenser
- Round Canisters for Straw Storage
- Lockable
- Roller Bases Available
Product Advantages
Narrow neck design and excellent thermal conduc-tivity reduces evapouration loss of liquid nitrogen to extend storage times.
Large-capacity models have wider necks for easy access to biological samples.
| Model | YR05403 | YR05404 | YR05405 | YR05406 | YR05407 | YR05408 | YR05409 | |
| Maximun Capacity | No. of Canister | 6（0） | ||||||
| No. of Straws (Single Layer) (0.5ml each canister) |
2244 | 792 | 2244 | |||||
| No. of Straws (Single Layer) (0.25ml each canister) |
5022 | 1788 | 5022 | |||||
| No. of Straws (Double Layer) (0.5ml each canister) |
3624 | 1284 | 3624 | |||||
| No. of Straws (Double Layer) (0.25ml each canister) |
8460 | 2832 | 8460 | |||||
| Performance | Volume of LN2 (L) | 30 | 35 | 35 | ||||
| Static Evapouration* (L/Day) | 0.21 | 0.12 | 0.22 | |||||
| Static Holding Time** (Day) | 147 | 286 | 159 | |||||
| Dimensions | Opening Diameter (mm) | 80 | 50 | 80 | ||||
| Height (mm) | 709 | 749 | 753 | |||||
| Outside Diameter (mm) | 462 | 462 | 462 | |||||
| Canister Outside Diameter (mm) | 63 | 38 | 63 | |||||
| Outside Height(mm) | 120 / 276 | |||||||
| Empty Weight (kg) | 13 | 14.2 | 14.5 | |||||
| Full Weight (kg) | 37 | 42.7 | 42.9 | |||||
| Shipping Weight (kg) | 18.3 | 20 | 20.7 | |||||
| Additional Features | Includes 6 canisters (height 276mm), lockable cap and protective jacket, roller base is optional |
Includes 6 canisters (height 120mm), lockable cap and protective jacket, roller base is optional |
Includes protective jacket only, roller base is optional |
Includes 6 canisters (height 276mm), lockable cap and protective jacket, roller base is optional |
Includes 6 canisters (height 120mm), lockable cap and protective jacket, roller base is optional |
Includes protective jacket only, roller base is optional |
Includes 6 canisters (height 276mm), lockable cap and protective jacket, roller base is optional |
|
| Model | YR05410 | YR05411 | YR05412 | YR05413 | YR05414 | YR05415 | YR05416 | |
| Maximun Capacity | No. of Canister | 6（0） | ||||||
| No. of Straws (Single Layer) (0.5ml each canister) |
2244 | 792 | 2244 | 5124 | 792 | |||
| No. of Straws (Single Layer) (0.25ml each canister) |
5022 | 1788 | 5022 | 11640 | 1788 | |||
| No. of Straws (Double Layer) (0.5ml each canister) |
3624 | 1284 | 3624 | 9048 | 1284 | |||
| No. of Straws (Double Layer) (0.25ml each canister) |
8460 | 2832 | 8460 | 20760 | 2832 | |||
| Performance | Volume of LN2 (L) | 35 | 20 | 30 | 35 | 35 | 35 | 50 |
| Static Evapouration* (L/Day) | 0.22 | 0.2 | 0.3 | 0.41 | 0.24 | |||
| Static Holding Time** (Day) | 159 | 101 | 159 | 179 | 119 | 86 | 213 | |
| Dimensions | Opening Diameter (mm) | 80 | 50 | 80 | 125 | 50 | ||
| Height (mm) | 753 | 672 | 705 | 749 | 753 | 748 | 810 | |
| Outside Diameter (mm) | 462 | 394 | 462 | 462 | 462 | 462 | ||
| Canister Outside Diameter (mm) | 63 | 38 | 63 | 97 | 38 | |||
| Outside Height(mm) | 120/276 | |||||||
| Empty Weight (kg) | 14.5 | 9.5 | 12.9 | 14.2 | 14.5 | 14.6 | 17.2 | |
| Full Weight (kg) | 42.9 | 27.9 | 37.1 | 42.8 | 43 | 43.5 | 60.3 | |
| Shipping Weight (kg) | 20.7 | 15.1 | 18.3 | 20.1 | 20.7 | 22 | 24 | |
| Additional Features | Includes protective jacket only, roller base is optional |
Includes protective jacket only. |
Includes protective jacket only, roller base is optional |
Includes protective jacket only, roller base is optional |
Includes protective jacket only, roller base is optional |
Includes protective jacket only. |
Includes protective jacket only, roller base is optional |
|
