Horizontal Laminar Flow Hood YR05727

ManufacturerKalstein

Description

The YR05727 Horizontal Laminar Flow Hood is a pivotal investment for laboratories that seek to maintain sterility and contamination-free environments. Designed with a sliding door system for arbitrary positioning, this hood allows the safe and efficient handling of samples while guarding against the entry of external particles. Built from a welded cold-rolled steel casing and a SUS304 brushed stainless steel worktop, the hood features corrosion-resistant properties, ensuring easy cleaning and high durability. Integrated with a high-efficiency HEPA filter and a primary pre-filtration unit, it maximizes air cleanliness in the workspace.

Market Price

The market price for the YR05727 laminar flow hood typically ranges from $1400 to $2200. This range reflects the hood’s superior material quality, state-of-the-art HEPA filtration technology, and ergonomic design that creates a clean and controlled work environment. For laboratories aiming to uphold rigorous cleanliness and safety standards, this investment is not just sensible but essential.

Frequently Asked Questions

  • What level of cleanliness does this hood provide?

    The YR05727 guarantees Class 100 cleanliness, perfect for protecting delicate work areas from contamination.
  • How are the lighting and sterilization systems controlled?
    The hood features a digital LCD interface, facilitating easy adjustments of lighting and UV lamp timing to maintain a safe and sterile environment.
  • Is it noisy during operation?
    No, the YR05727 operates quietly with a noise level of ≤62dB, making it suitable for laboratories requiring low-noise environments.

Advantages and Disadvantages

The YR05727 offers numerous advantages, such as a robust stainless steel build, an efficient HEPA filtration system, and reduced noise levels. Its ergonomic design and intuitive interface enhance usability in any lab setting. However, the price may be considered high for budget-conscious laboratories, though the long-term performance justifies the expense.

Field Use

The YR05727 laminar flow hood excels in research, pharmaceutical, and electronics laboratories where high sterility is essential for handling sensitive samples. Its horizontal airflow system prevents the intrusion of contaminants, vital for manufacturing medical and electronic products, as well as for research processes that demand a high level of cleanliness.

Recommendations

To ensure optimal performance and longevity of the YR05727 laminar flow hood, regular maintenance is crucial, including cleaning the air filters and inspecting the UV sterilization system. It is equally important to maintain the airflow within recommended parameters to prevent contaminant buildup. Don’t miss the chance to enhance your laboratory’s safety and efficiency. Request a quote today via Kalstein Plus and see how the YR05727 can revolutionize your workspace with consistent sterility and control.

Features

  • Welded cold-rolled steel casing
  • SUS304 brushed stainless steel worktop
  • High-efficiency HEPA and primary pre-filters
  • Digital LCD interface for lighting and UV settings
  • Arbitrary positioning sliding door system
  • Low noise level operation

Technical Specifications

Model YR05727
Cleanliness Level Class 100@≥0.5μM (US Federal 209E)
Number of Colonies ≤0.5pcs/dish·hour (Φ90mm culture plate)
Average Wind Speed 0.25~0.45m/s
Noise ≤62dB(A)
Vibration Half Peak ≤5μM(x、y、z direction)
Illuminance ≥300Lx
Power Supply AC single phase 220V/50Hz
Maximum Power 500W
Weight 110kg
Work area size
W1×D1×H1
1150××410×580
1310×590×1600
Dimensions Double single
High efficiency filter specification and quantity 1130×565×50
Specification and quantity of fluorescent lamp/ultraviolet lamp 12W×1
30W×1

Additional information

Weight 220 kg
Dimensions 139 × 68 × 170 cm
