Description
Test range from 1 to 100,000 mpa.s (cps)
High accuracy
Automatic detection
Easy to operate
Attachments:
- No. 1,2,3,4 Spindles
- No. 0 Spindle
- Adapter
- Protection Frame
- Foundation Plate
- Up-Down Frame
- English Manual
- Hexagonal Spanner
- Solid Wrench
Technical Description:
Model | YR05853 | YR05854 |
Measurement Range | 1-100,000 mpa.s | |
Display | LCD | |
Spindles Specification | No. 0, 1, 2, 3, 4 | |
Note: The bigger the number of the Spindles, the bigger the measuring value | ||
Rotating Speed of Spindles | 6 / 12 / 30 / 60 rpm/min. | |
Interface | Optional | |
(RS232C, temperature probe, edit software CD) | ||
Automatic Switch | free selection of proper rotating speed or spindles number. | |
Stable Cursor | Strip-type cursor fully charged displayed when reading basically stable | |
Measurement Tolerance | ± 2% | |
Power | AC 220V ± 10% 50 Hz ± 10% | |
Working Condition | Temperature 5-35 degree | |
Relative humidity no more than 80% | ||
Outline Dimension (mm) | 370×325×280 mm | |
Packing (mm) | 400×360×310 mm | |
Net Weight (kg) | 6.8 kg | |
Gross Weight (kg) | 9 kg | |
Additional Information | 6,12,30,60 rpm/min | |
Mpa.S | 1-100,000 cps |
