Description
Equipped with a 2.5 inches LCD screen to give a clear display of standard curves and groups of results.
Standard curve
Can set up various standard curves according to customer ‘s solutions and find the concentration of unknown solutions.
Imported deuterium lamp
YR01851 is equipped with imported deuterium lamp which ensures low stray light,photometericaccuracy and is easy to be replaced.
Data output
Equipped with USB port to connected with a PC to display spectrum scanning,kinetics and Multi wavelength testing results on the screen.The software is optional
Multiple results readout
Can display wavelength,absorption and transmittance with 5 results per screen.It also has a memory store of up to 200 results.
Auto setting wavelength
Users set wavelength automatically through arrow keys to avoid operation errors.
| Model | YR01851 |
| Optical System | Single beam, Grating 1200 lines/mm |
| Wavelength Range | 190-1000nm |
| Bandwidth | 2nm |
| Wavelength Accuracy | ±2nm |
| Wavelength Repeatability | 0.5nm |
| Wavelength Setting | Auto |
| Photometric Accuracy | ±0.5%T |
| Photometric Repeatability | ≤0.2%T |
| Photometric Range | -0.3-3A, 0-200%T, 0-9999C |
| Photometric Mode | T, A, C, F |
| Stray Light | ≤0.1%T |
| Stability | ± 0.002A/h @ 500nm |
| Display | 128*64 LCD |
| Detector | Silicon Photodiode |
| Light Source | Tungsten Lamp & Deuterium Lamp |
| Output | USB & Parallel Port (Printer) |
| Power Requirements | AC 85~250V |
| Dimension | 420*280*180mm |
| Weight | 11kg |
| Item | Description | Quantity | Unit |
| 1 | Spectrophotometer | 1 | set |
| 2 | 1cm Glass cuvette | 4 | pcs |
| 3 | Power cord | 1 | pcs |
| 4 | User’s Manual | 1 | pcs |
| 5 | 1cm quartz cuvette | 2 | pcs |
