Description
Test the viscosity of Newtonian and non-Newtonian liquids
No. 0 Spindles can test 1-10 mpa.s.
Attachments:
- No. 1,2,3,4 Spindles
- No. 0 Spindles is optional
- Adapter
- Protection Frame
- Foundation Plate
- Up-Down Frame
- English Manual
- Hexagonal Spanner
- Solid Wrench
Technical Description:
| Model | YR05851 | YR05852 |
| Measurement Range | 1-100,000 mpa.s | 1-2,000,000 mpa.s |
| Spindles Specification | No. 1, 2, 3, 4 ( NO. 0 is optional) | |
| Note: The bigger the number of the Spindles, the bigger the measuring value | ||
| Rotating Speed of Spindles | 6 / 12 / 30 / 60 rpm/min. | |
| Interface | No | |
| Measurement Tolerance | ± 5% | |
| Power | AC 220V ± 10% 50 Hz ± 10% | |
| Working Condition | Temperature 5-35 degree | |
| Relative humidity no more than 80% | ||
| Outline Dimension (mm) | 280×290×450 mm | |
| Packing (mm) | 470×300×420 mm | |
| Net Weight (kg) | 2 kg | |
| Gross Weight (kg) | 5 kg | |
| Additional Information | 6,12,30,60 circle/m | 0.3, 0.6, 1.5, 3, 6,12,30,60 circle/m |
| Mpa.S | 1-100,000 cps | 1-2,000,000 cps |
