Ion Meter
An ion meter is an analytical and electrochemical instrument used to measure the concentration of ions in a solution, using ion electrodes (ISE).
A selective ion electrode is a kind of sensor that allows to test ions in various types of samples, whether environmental, pharmaceutical, biotechnological, food, agricultural, industrial, drinking water, wastewater among others. The most commonly tested ions include ammonia, nitrate, chloride, fluoride, calcium, sodium, potassium, silver, iodide, sulfide, lead, bromine, cadmium, copper and others.
An ion is an atom or group of electrically charged atoms. This molecule may have a positive or negative charge. A cation is an ion with a positive charge and an anion is one with a negative charge (atom or molecule). Ions are formed when a neutral (electrically neutral) atom loses or gains electrons. Anions have more electrons than protons and cations have a higher proton number.
Types of Ion Meter a Laboratory May Need
Portable
• Professional portable ammonium ion meter is equipped with a backlit LCD display.
• 2 to 5 points calibration from low to high concentrations.
• Selectable 8 concentration calibration points, including the 0.001 to 10000.
• Selectable concentration units – ppm, mg/L and mol/L.
• Automatic electrode diagnosis shows the calibration points and slopes.
• Automatic temperature compensation ensures accurate readings over the entire range.
• Direct ion concentration readout simplifies the measurement process.
In Kalstein you can find the Ideal ion Meter for your Laboratory
Portable Ion Meter YR01817 // YR01817-15
The professional portable ammonium ion meter is equipped with a backlit LCD display. Calibration from 2 to 5 points from low to high concentrations. Selectable concentration calibration points from 8, including 0.001 to 10000..
YR01816 Portable pH / Ion Meter
Multiparameter portable ion meter, 2 to 5 points calibration, selectable ion concentration units. The meter is suitable for measuring the pH, mV and ion concentration, accuracy: 0.5% F.S. 2 to 5 points calibration, including the 8 concentration points can be selected...
Our Best Selling Ion Meter
These innovative equipment currently have many utilities, but it is used more frequently to measure and control water purity. Because pure water is required for many laboratory and clinical procedures. Moreover, that drinking water for consumption, should be as optimal as possible to avoid diseases and health conditions of people.
What is an ion?
An ion is an atom or group of electrically charged atoms. This molecule may have a positive or negative charge. A cation is an ion with a positive charge and an anion is one with a negative charge (atom or molecule).
| Model | YR01816 |
| pH | |
| Range | -2.000 to 20.000pH |
| Resolution | 0.001, 0.01, 0.1pH, selectable |
| Accuracy | ±0.002pH |
| Calibration Points | 1 to 5 points |
| pH Buffer Options | USA, NIST, DIN, 2 custom buffers |
| ORP | |
| Range | ±1999.9mV |
| Resolution | 0.1, 1mV, selectable |
| Accuracy | ±0.2mV |
| Calibration Points | 1 point |
| Measurement Modes | Relative or absolute mV |
| Ion Concentration | |
| Range | 0.001 to 19999 (deponding on the range of ISE) |
| Resolution | 0.001, 0.01, 0.1, 1 |
| Accuracy | ±0.5% F.S. (monovalent), ±1% F.S. (divalent) |
| Calibration Points | 2 to 5 points |
| Calibration Solutions | 0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000 |
| Measurement Units | ppm, mg/L, mol/L, mmol/L |
| Temperature | |
| Range | 0 to 105°C/32 to 221°F |
| Resolution | 0.1°C/0.1°F |
| Accuracy | ±0.5°C/±0.9°F |
| Offset Calibration | 1 point |
| Calibration Range | Reading ±10°C |
| General Specifications | |
| Temperature Compensation | 0 to 100°C/32 to 212°F, manual or automatic |
| Stability Criteria | Low or high |
| Calibration Due Alarm | 1 to 31 days or off |
| Auto-Power Off | 10, 20 or 30 minutes after last key pressed |
| Memory | Stores up to 500 data sets |
| Output | USB communication interface |
| Connector | BNC, 3.5mm jack socket |
| Display | Custom LCD (80×60mm) |
| Power | 3×1.5V AA batteries or DC5V power adapter |
| Battery Life | Approximately 150 hours (turn off the backlight) |
| Dimensions | 170(L)×85(W)×30(H)mm |
| Weight | 300g |
Analysis of the best Ion Meters for your Laboratory
Functions of pH Ion Meters in the Cosmetic Industry
In the manufacture of cosmetic products there are three essential aspects that must be addressed, the first...
What are the characteristics of an ion meter?
An ion meter is an electrochemical analytical device that is used to measure ion concentration in a solution...
What is the ion meter used for?
The ion meter is a piece of equipment used to detect the concentration or activity of ions in a solution...
Ion and Conductivity Meters: Differences
Today’s ion meters are based on the ion-selective electrode technique. These are measuring instruments...
Ion Meter Models Catalog on Sale
Guides to becoming an expert in Ion Meter
Water hardness determined with Calcium Ion Meters
Water hardness refers to the amount of calcium and magnesium dissolved in water. The term comes from the ability of water to consume...
Food Analysis Using the Potassium Ion Meter
The potassium meter is a portable, safe and easy-to-use device. This device is essential for laboratory professionals ...
Copper Ion Meters for Pool Disinfection - Laboratory
In recent years the use of chlorine for swimming pool disinfection has been replaced by ionization with copper ...
What are the differences between: PH Meter, Ion Meter and Conductivity Meter?
Firstly, measuring instruments are important and fundamental in laboratories, they are equipment that are created to provide a solution to professionals, for monitoring their activities...
Videos of Ion meter
In this section you can find, our Ion meter running, packaged, receiving service, etc.
Ion Meter in operation
The ion meter is a piece of equipment used to detect the concentration or activity of ions in a solution. There are different types of ion meters; some are designed to measure a specific ion.
Ion meters are used for multiple purposes, and in many areas; as it is in mining, livestock, laboratory, agriculture, arts, food industry, drinking and waste water, among many others.
Ion Meter Utilities
- Measurement of calcium in water: this helps consumers to accurately understand their calcium intake.
- Determination of potassium in sea water
Frequently Asked Questions about Ion Meters
How to know the prices of Ion Meters?
To know the price of the Ion Meter we invite you to send us an email with your request through the contact form..
What are the delivery times of the Ion Meters?
- If the equipment of your interest is in stock or if it must be manufactured.
- The type of freight you have chosen, this may be; air or sea.
How to make a purchase of Ion Meters?
- By email: sales@kalstein.eu
- By telephone: +33 (0) 1 78 95 87 02
- E-commerce: Via Kalstein's official website in your country.
How does the warranty work?
Can I request a quote online?
Of course, you can request a quote for the Kalstein team of your interest, directly from our official website. Once you have identified your preferred model, click HERE
