Description
- Fully automatic and self-diagnostic system monitors and controls working condition.
- PIN-coded access to software set points prevents unauthorized changes to operation or system settings.
Comprehensive Sanitization
- Unlike many other systems, Kalstein entire fluid pathway is included in the automated disinfection process ensuring complete sanitization.
Module-designed Cartridges
- High quality and economical due to disposable integrated purification column design.
- Easy replacement and quick connection.
High precision resistivity meter
- Flow-through structure make sure the real-time measurement of the actual ionic concentration in water
- Low cell constant (0.01cm-1) to ensure optimum measurement accuracy of low ionic contamination
- Automatic temperature compensation (0.1℃ resolution) makes the value displayed on the screen meaningful
Easy-to-read LCD display
- User-friendly LCD provides optimal convenience, with indication on resistivity, resistivity, reservoirs water consumable changing reminder water quality.
Optional strengthened pre-treatment module
- 20′ size long cartridge contrains detergent. Therefore, besides the feature of higher water throughput, feed water with extremely low quality can be properly dealt with
Contamination-Free Water Tank
- Water level sensor combined with bottom pump enables 5-level automatic water production controls
- Capacity of water reservoir includes 30L and 60L. Moreover, ultra big 350L water reservoir is available for special needs
- The water reservoir is made through cylindrical mold and blow molding process to avoid the generation of velum
- PE material ensure low extractives
- Overflow protection tube eliminates the risk of flooding
- Cone shape bottom guarantees no stagnant water and facilitates easy clean
- Optional UV lamp and vented filter maintain consistent purity of stored water and provide effective protection against airborne contaminants
Network Compatible
- RS232 port allows for data collection and permanent record of water quality and system parameters, with date and time, to a PC or printer – essential for compliance with good laboratory practice guidelines
Technical Specification:
Model | YR59 | YR59-1 |
Particles | (≤0.22μm): ≤1/ml | |
Output (pure water) | 30L/hr output (pure water) | |
TOC | ≤30ppb | |
Bacteria rejection rate | >99% | |
Weight | 37KG (main unit) 13KG (water tank) | |
Source | Purewater (Conductivity <20 μs/cm) | |
Voltage | 230 V, 50 Hz | |
Resistivity at 25 ℃ | 18.2MΩ.cm | |
Conductivity at 25 ℃ | 0.055 μs/cm | |
Flow Rate | 1.5-2.0L/min | |
Resistivity Cell | 0.01cm -1 |
