Special Designed Sample Digestion Vessel. The automatic vent and self-resealing structure which won national patent ensures the digestion vessels can automatically release pressure and instantly reseal when a sudden over-pressure situation occurs. It prevents waste of batch samples and solutions and also avoids vessel damage.
The advanced contact-less IR sensor could measure the real-time temperature of sample solutions in each digestion vessel. Meanwhile, the contact-less pressure sensor could monitor the real-time pressure of each vessel. This realizes isolation between temperature and pressure controlling system, also avoids sample cross-contamination. Each real-time temperature and pressure value is displayed during the whole digestion process, allowing a clear check of digestion conditions.
It can edit and store 255 types of programs according to user’s requirements and each method program can set parameters (temperature, pressure, time, microwave power) according to their own requirements which provides convenient operation for users.
With high-strength double locked security door, the real-time temperature and pressure monitoring, automatic adjustment of over-pressure and over-temperature and abnormal sound monitoring, the device can run in a highly safe environment.
The variable frequency resonance or non-pulse(optional) continues rotating mode ensures high efficient and even microwave throughput. It can be set between 0~3000W according to user’s requirements.
|Air Exhaust||High power corrosion-proof air blower|
|Protection Vessel Material||Peek+Glass Fiber|
|Rotation||One Direction 360° continuous rotating|
|Microwave Tank||316L stainless steel tank with corrosion-proof coating|
|Sample Vessel Material||Imported TFM|
|Power||AC 220V±10%, 10A, 50/60Hz|
|Display||7 inch Color Touch Screen|
|Pressure Monitoring System||Contactless Sensor Pressure monitoring|
|Each Vessels Pressure Controlled|
|Pressure Controlling Range: 0~10MPa|
|Pressure Accuracy: ±0.01MPa|
|Display Accuracy: ±0.01Mpa|
|Temperature Monitoring System||Contactless IR Sensor Temperature Monitoring|
|Each Vessel Temperature Controlled|
|Temperature Controlling Range: 50~400°C|
|Temperature Accuracy: ±0.3°C|
|Display Accuracy: ±0.1°C|
|Microwave Power||0-2000W (Adjustable)|
|Dimension||AC 220V±10%, 10A, 50/60Hz|
