These are laboratory instruments are small appliances that have one or more elements of electric heating, in addition they have a structure resistant to chemical spills, as well as corrosion; its main purpose is to heat containers of different materials with liquid content, always uniformly and controlled; we can find on the market different models with specific features that will depend on your applications.
The variety of models and types of heating plates will depend on the manufacturer, in this case, we KALSTEIN as Company Manufacturer of Laboratory Equipment, we offer a YR series that its high-tech designs and manufactured with the best materials ensure an efficient and effective process, in addition to offering advice and accompaniment during installation.
Magnetic stirrers are often used in chemistry and biology. They are preferred to motorized...
Magnetic stirrers are often used in chemistry and biology. They are preferred over gear...
They do not require lubricants that may contaminate the reaction vessel and product...
without the need for complicated swivel seals. Magnetic stirrers may also include a plate....
Magnetic stirrers are often used in chemistry and biology. They are preferred over gear-driven motorized stirrers because they are quieter, more efficient, and have no moving external parts to break or wear out (other than the simple bar magnet itself). Because of its small size, a stirring bar is more easily cleaned and sterilized than other stirring devices. They do not require lubricants which could contaminate the reaction vessel and the product. They can be used inside hermetically closed vessels or systems, without the need for complicated rotary seals. Magnetic stirrers may also include a hot plate or some other means for heating the liquid.
| Model | YR02941 |
| Top Plate Dimension (mm) | 140 x 140 |
| Top Plate Dimension(Inch) | 5.51 x 5.51 |
| Temperature Control | PID Auto control . |
| Top Plate Shape | Round or Square |
| Top Plate Material | Ceramic |
| Temperature Range for machine | Ambient to 400 degree. |
| Max Temperature for top plate | 325 degree |
| Top Material | White ceramics and Black Ceramic are Both available . |
| Temperature Display (°C ) | Digital Display |
| Temperature control | PID Auto control |
| Temperature accuracy | |
| Thermocouple probe /sensor type | PT100 , with inner and outer thermocouple . |
| Stir Speed | 100- 1800 RPM |
| Stir Display | Digital display |
| Stir speed accuracy | |
| Permissible Ambient Temperature | Ambient Temperature to 40°C |
| Voltage | 160 – 240V , or 110- 130V. |
| Heating Power supply (w) | 450 |
| Motor Power supply | 40 W.DC 20 |
| Machine power supply | 500 |
| Stirring Flask Capacity (ml) | 50ML – 2L |
| Overall Dimensions (mm) ( L × W × H ) |
295 x 190 x 104 |
| Packing Dimension (mm) | 350 x 250 x 150 |
| Shipping Weight (kg) | 3.5kg. |
| Shell material | Time molding waterproof and dustproof shell with Anti-static paint |
The heating plate is a laboratory instrument desktop and portable comprised electric heating elements and corrosion resistant to chemical and mechanical attacks...
The heating plate is benchtop laboratory equipment whose function is to heat containers with liquids in a ...
The heating and stirring plate is the ideal equipment for laboratory practices, able to offer precise temperature...
The multi-station heating plate is a benchtop and portable laboratory instrument that adapts to multiple....
Hotplate Stirrers are benchtop electronic equipment that adapt to multiple processes that require temperature and stirring. That is, they...
These are laboratory instruments are small appliances that have one or more elements of electric heating, in addition they have...
A hot plate is crucial laboratory equipment for carrying out many of the processes carried out in laboratories, such as distillation, boiling...
Heating plates or plates are small laboratory instruments that have a structure of excellent resistance to chemical and mechanical attacks, as well as corrosion in general, this tabletop device is portable and autonomous, has one or more electric heating elements, allows heating containers with liquids in a controlled way.
To know the price of the Heating Plates we invite you to send us an email with your request through the contact form.
The delivery time of your Kalstein product will depend on the following:
– Delivery Time (Aereo): 15-30 days.
– Delivery Time (Maritimo): 45-60 days.
– Delivery Time (Aereo): 30-60 days.
– Delivery Time (Maritimo): 60-90 days.
You can make your purchase through:
At Kalstein we provide our customers with inductions and technical support through new online methods. You can visit our inductions, technical assistance and guidance videos provided by a Kalstein team through our YouTube channel (Kalstein English). HERE
