Nine – Point Magnetic Stirring Hot Plate for Laboratory YR02946

Manufacturer: Kalstein


Magnetic stirrers are often used in chemistry and biology. They are preferred over gear-driven motorized stirrers because they are quieter, more efficient, and have no moving external parts to break or wear out (other than the simple bar magnet itself). Because of its small size, a stirring bar is more easily cleaned and sterilized than other stirring devices. They do not require lubricants which could contaminate the reaction vessel and the product. They can be used inside hermetically closed vessels or systems, without the need for complicated rotary seals. Magnetic stirrers may also include a hot plate or some other means for heating the liquid.

Product Features
  • Very compact and simple to operate
  • Digital Display temperature and speed, Heating temperature: Rt-380 Degree and mixing speed :100-1800 RPM
  • Heat and corrosion resistant aluminium alloy housing for durability
  • Ceramic coated aluminum heating plate for great heat distribution and corrosion resistance
  • Specially designed housing prevents spill from damaging the electronic components inside
  • Secondary heat insulation plate prevents heat loss and eliminates heat damage to electronic components
  • Adjustable temperature and rotation speed
Model YR02946
Temperature adjustable multipoint magnetic stirrer
Specification 9 points
Temperature The surface temperature can be up to 350ยฐC
Heating area 280mm ร— 280mm
Power of heating 750W
Temperature control type Stepless voltage adjustable ,0~220V controlled silicon controlling
Presion of temperature controlling ยฑ 5ยฐC
Heating wire Cr20Ni80
Material TU2 red copper
Capacity 9 points :9ร—250ml
Power of the motor 9ร—8W
Range of speed adjustment 0-2000 rpm (digital display of speed )
Power supply 220V 50HZ
Working time Continous
Overal dimension 500 ร— 330 ร— 150mm
Packing dimension 550 ร— 380 ร— 200mm
Weight 9500 ยฑ 200g

Additional information

Weight 9,00 kg
Dimensions 48 × 28 × 30 cm
