YR01830 Benchtop TDS / Conductivity Meter

Manufacturer:ย Kalstein

Description

  • 5-inch LCD screen with 150ยฐ viewing angle for clear reading out of 5-meter.
  • Built-in microprocessor chip has Intelligent functions such as automatic calibration, ATC, data storage, clock display, USB output, function settings, automatic power-off and low voltage alarm, etc.
  • Two USB interfaces for PC connection, battery charging, and data transfer.
  • 3.5mm electrode interface makes it very easy for electrode connection.
  • Automatic recognition of different electrodes. The electrode with built-in chip can automatically stores and retrieve calibration data after connecting with meter.
  • Can store 300 sets of data including readings, GLP data, date and time
  • Rechargeable battery can last for 30 hours. Auto power off when no operation in 10 minutes.
  • Adopt advanced conductivity measurement technology, with conductivity electrode (K=1), it can meet measuring accuracy requirement for range of 0.5ฮผS/cm ~ 200mS/cm
  • Can switch among conductivity, TDS, Salinity and Resistivity. Multinomial calculation for TDS and salinity to ensure the conversion precision of the full scale.
  • Auto recognition of 8 conductivity standard solution with 2 kinds of options: Europe &USA and China.
Technical Specifications
Model YR01830
Conductivity
Measuring range
Conductivity: (0.00~20.00)ฮผS/cm; (20.0~200.0)ฮผS/cm; (200~2000)ฮผS/cm; (2.00~20.00)mS/cm; (20.0~200.0)mS/cm
TDS: (0~100) g/L
Salinity:(0 ~ 100)ppt
Resistivity:(0 ~ 100)Mฮฉยทcm
Resolution 0.01/0.1/1ฮผS/cm; 0.01/0.1mS/cm
Accuracy Meter: ยฑ1.50% FS; Electrode: ยฑ1.0% FS
Temp. compensation range (0 ~ 50)ยบC , auto
Electrode constant 0.1 / 1 / 10 cm-1
Temperature
Measuring range (-10 ~ 110)ยบC
Resolution 0.1ยบC
Accuracy 5~ 60ยบC: range: ยฑ0.5ยบC; other range: ยฑ1.0ยบC
Other Technical Parameters
Display 5-Inch white backlit LCD screen
Data storage 300 sets
Power DC 5V/1A
Communication connector Micro USB & Standard USB
Dimension/N.W. 180 x 130 x 14mm/280g
Working Condition
Environment Temp. 5 ~ 35 ยบC
Environmental โ‰ค85%
IP Grade IP54

Additional information

Weight 3 kg
Dimensions 47 × 43 × 8 cm
